In addition, electrode paste customers are also concerned about high electrode paste consumption. This issue is arguably the most critical concern for customers before electrode breakage occurs, as it directly affects production costs. A 10% increase in electrode paste consumption means a 0.5% to 2% rise in product cost, which inevitably impacts sales and, consequently, company performance. Therefore, many customers inquire about electrode paste consumption when purchasing. However, as previously mentioned, electrode paste consumption is a comprehensive outcome influenced by multiple factors, not solely determined by the quality of the paste itself. Today, we will analyze the causes behind high electrode paste consumption, aiming to help more people understand this issue and address it promptly to avoid disruptions in production.

The main reasons for high electrode paste consumption can be attributed to three aspects: product quality issues, improper operating procedures, and equipment management deficiencies.

1) Unreasonable ash content in electrode paste is a key factor. Excessively high ash content slows down sintering and accelerates consumption; too low ash content results in insufficient baking strength, increasing the risk of hard breaks. Proper control of ash content helps balance sintering and consumption rates.

2) Low fixed carbon content leads to rapid electrode consumption. Fixed carbon directly affects the electrical conductivity and thermal stability of electrode paste. Higher fixed carbon content increases the proportion of carbon materials, reduces the amount of carbon involved in chemical reactions, and thus lowers consumption rate. Conversely, low fixed carbon accelerates oxidation and consumption.

1) Inappropriate pressing and lowering operations: excessive lowering length or short intervals between operations lead to under-baking, accelerating consumption. Frequent adjustments or excessively high current may cause paste leakage or soft breakage.

2) Improper electrode depth control: excessive fluctuations in feeding depth disrupt thermal balance, reducing baking quality. If both working length and furnace insertion depth are too short, electrode consumption increases rapidly.

3) Overloading of the electric furnace causes accelerated electrode wear. High-current baking intensifies electrode consumption. Under high-current conditions, oxidizing gases such as oxygen and carbon dioxide from the furnace atmosphere penetrate through electrode gaps, react with the electrode surface, and accelerate consumption.

4) High secondary voltage with low current also increases electrode consumption. Elevated secondary voltage alters arc length, potentially accelerating surface oxidation of the paste. In high-voltage environments, higher arc temperatures accelerate decomposition of organic components in the paste, increasing consumption.

5) Rising furnace bottom reduces electrode insertion depth, leading to faster consumption. This is easy to understand—shallow electrode insertion increases exposed arc phenomena, raises oxidation and temperature, and naturally increases consumption.

1) Design flaws in electrode sleeves: mismatch between sleeve inner diameter and paste column height creates pressure imbalance, causing stratification or sleeve expansion.

2) Incorrect paste-feeding methods: adding too much paste at once exceeds the electrode’s weight limit, resulting in paste leakage or sleeve slippage.

Customers of Rongxing electrode paste have occasionally reported similar issues. Upon receiving feedback, Rongxing engineers immediately contact workshop supervisors, using video inspections or on-site assessments to identify the root cause and provide timely solutions. When high consumption results from operational practices or other non-quality-related factors, customers often show understanding and make necessary adjustments as recommended. Thanks to their trust and support in Rongxing's product quality, many customers have maintained long-term cooperation with us. We sincerely appreciate your confidence. Rongxing electrode paste will continue to place customer needs at the center, consistently delivering the most comprehensive service and best-suited products.
